Englander Blue Ridge 100 Wood Stove
The Englander Blue Ridge 100 Wood Stove is a cutting-edge heating appliance that offers an array of features designed to provide an efficient and aesthetically pleasing addition to any home. Here's an overview of its distinctive characteristics:
- High Efficiency 1.8 ft³ Firebox: The compact firebox size of 1.8 cubic feet makes this stove ideal for tight spaces, without compromising on performance.
- Up to 5 Hours Burn Time: Enjoy warmth for extended periods, with a burn time of up to 5 hours.
- Steel Top Reinforced with Stainless Steel Heat Shield: Built for durability and heat retention, the steel top is further reinforced with a stainless steel heat shield.
- Cast Iron Door and Ceramic Glass: These features add both elegance and functionality, ensuring that the stove retains heat while providing a clear view of the burning wood.
- EPA Certified: Complying with environmental regulations, this stove is EPA certified, reflecting its commitment to eco-friendly operation.
- Proudly Made in the USA: Manufactured with pride in the United States, it stands as a testament to domestic craftsmanship.
- Non-Catalytic Combustion System: The non-catalytic combustion system is designed for efficiency and simplicity, providing a cleaner burn and easier maintenance.
- Certified for Mobile Home and Alcove Installation: With this certification, the stove can be safely installed in various types of homes, including mobile homes and alcoves.
- Qualifies for the 30% US Tax Credit: Potential financial benefits include qualification for a 30% US tax credit, offering a significant cost-saving advantage.
- Included Accessories: The stove comes with a number of useful extras such as a pedestal, ash lip, air intake damper, and rear air deflector, enhancing its functionality and ease of use.
Overall, the Englander Blue Ridge 100 Wood Stove provides a robust, efficient, and visually appealing heating solution, meeting the needs of various users while offering potential financial benefits. Whether for a conventional home or a mobile one, this stove is sure to be a valuable investment.
| Fuel type | Dry cordwood (16" recommended) |
| Recommended heating area | 250 - 1,200 ft² |
| Overall firebox volume | 1.8 ft³ |
| EPA loading volume | 1.55 ft³ |
| Maximum burn time | 5 h |
| Maximum heat output-dry cordwood | 45,000 BTU/h (13.2 kW) |
| Minimum overall heat output rate | 12,124 BTU/h (3.55 kW) |
| Maximum overall heat output rate | 26,700 BTU/h (7.83 kW) |
| Average overall efficiency-dry cordwood (HHV) | 74 % |
| Average overall efficiency-dry cordwood (LHV) | 79 % |
| Optimum efficiency | 80 % |
| Optimum heat transfer efficiency | 79 % |
| Average particulate emission rate | 1.8 g/h |
| Average CO | 74 g/h |
| From serial # | 100 |
| Certifications | EPA-2020 |
| Short description | High efficiency 1.8 ft³ firebox, ideal for tight spaces. |
| Alcove installation approved | Yes |
| Mobile home approved | Yes, with fresh air intake |
| Certified according to applicable standards | By an accredited laboratory (CAN/USA) |
| Overall dimension (Width) | 18 1/2" |
| Overall dimension (Height) | 30 5/8" |
| Overall dimension (Depth) | 29" |
| Premium quality blower included (CFM) | Optional |
| Combustion technology | Non catalytic |
| Stainless-steel secondary-air system | Yes |
| Flue outlet diameter | 6" |
| Distance-center of the flue outlet to back unit | 6 5/8" |
| Distance-center of the flue outlet to side unit | 9 1/4" |
| Recommended chimney diameter | 6" |
| Type of chimney | CAN/ULC S629, UL 103 HT (2100 °F) |
| Minimum chimney height | 12' |
| Door type | Single, glass with cast iron frame |
| Door opening size (Width) | 12" |
| Door opening size (Height) | 7 5/8" |
| Glass type | Ceramic glass |
| Glass surface - W x H | 9 5/8" x 8 1/8" |
| Steel thickness-body | 3/16" |
| Steel thickness-top | 1/4" |
| Firebox size (Width) | 14 1/4" |
| Firebox size (Height) | 11 3/4" |
| Firebox size (Depth) | 19 3/8" |
| Log positioning | Loading over depth |
| Maximum log length | 17" (16" recommanded) |
| Firebox lined with refractory bricks | Yes |
| Baffle type | High quality vermiculite |
| High-efficiency certified appliance | Yes, EPA 2020 approved |
| Canadian Standard (emissions) | CSA B415.1-10 |
| USA Standard (emissions) | EPA |
| Canadian Standard (safety) | ULC S627 |
| USA Standard (safety) | 1482, UL 737 |
| Warranty | 5 years limited |
| Canada | United States | ||
|---|---|---|---|
| Single wall pipe | Double wall pipe | Single wall pipe | Double wall pipe |
| Clearance - Back wall | |||
| 14" | 6" | 12" | 6" |
| Clearance - Side wall | |||
| 18" | 18" | 18" | 18" |
| Clearance - Corner | |||
| 11" | 7" | 11" | 7" |
| Clearance - Base of the unit to ceiling** | |||
| 84" | 84" | 84" | 84" |
