ENGLANDER 25-PDVC PELLET STOVE ESW0019
Product Description
Experience the allure of the Englander 25-CBPAH Pellet Stove, our most popular compact model, and understand why it's our all-time best-seller.
With our renowned auto-start igniter and user-friendly control board, this stove promises hassle-free operation at your fingertips.
Though it's a top-performing pellet stove praised in numerous publications, it's economically priced to save you hundreds against other premium brands.
Warming up to 1,500 sq. ft., this stove delivers substantial heat. An air wash system enhances your enjoyment of the fire's view, and its adaptability to thermostats and approval for Mobile Homes adds to its appeal.
Features
- Manufactured in the USA
- Capable of heating up to 1,500 sq. ft.
- Hopper with a 40 lb. capacity for wood pellets
- Provides up to 25 hours of burn time per filling
- Latest EPA certification ensures High Efficiency and Low Emissions
- Approval for Mobile Home installation
- Includes Outside Air Kit
Specifications
| Fuel type | Premium Grade Wood Pellets |
| Recommended heating area | Up to 1,500 ft² |
| Hopper capacity | 40 lb |
| Maximum burn time | 20 h |
| Maximum heat input rate | 34,830 BTU/h (10 kW) |
| Minimum overall heat output rate | 11,220 BTU/h (3.3 kW) |
| Maximum overall heat output rate | 26,179 BTU/h (7.7 kW) |
| Minimum average overall efficiency (HHV) | 63.9% |
| Maximum average overall efficiency (LHV) | 75.5% |
| Optimum efficiency | 81.3% |
| Optimum heat transfer efficiency | 81.70% |
| Burn rate | 1.84 - 4.05 lb/h |
| Average particulate emission rate | 1.43 g/h |
| Average CO | 0.0 g/h |
| Average electrical power consumption for ignition cycle | 5.7A (668 W) |
| Average electrical power consumption for continuous operation | 3.2A (368 W) |
| From serial # | 150000 |
| Short description | See (and feel) for yourself what makes this attractive, compact pellet stove our best-selling pellet stove of all time. |
| Mobile home approved | Yes, with fresh air intake |
| Certified according to applicable standards | By an accredited laboratory (CAN/USA) |
| Premium quality blower included (CFM) | 140 CFM included |
| Combustion technology | Bottom-feed |
| Baffle type | Mild steel |
| Flue outlet diameter | 3" |
| Recommended chimney diameter | 3"-4" |
| Type of chimney | ULC/ORD-C441, CAN/ULC S609, UL 641 (TYPE L) |
| Overall dimension (Width) | 23" |
| Overall dimension (Height) | 28 1/2" |
| Overall dimension (Depth) | 20" |
| Voltage and frequency | 120 VAC / 60 Hz |
| Door type | Single, glass with cast iron frame |
| Glass type | Ceramic glass Ceramic glass |
| Glass surface - W x H | 8" x 8" |
| High-efficiency certified appliance | Yes, EPA 2020 approved |
| Canadian Standard (emissions) | CSA B415.1-10 |
| USA Standard (emissions) | EPA, ASTM E2779 |
| Canadian Standard (safety) | ULC S627 |
| USA Standard (safety) | UL 1482, ASTM E1509 |
| Warranty | 5 year Limited |
| Shipping weight | 285 LB |
Resources
See user manual for other installation requirements.
| CLEARANCE TO COMBUSTIBLES* | Canada | United States |
|---|---|---|
| Clearance - Back wall | 3" | 3" |
| Clearance - Side wall | 6" | 6" |
| Clearance - Corner | 6" | 6" |
| Clearance - Base of the unit to ceiling** | 48" | 48" |
*The information given on the certification label affixed to the appliance always overrides the information published in any other media (owner's manual, catalogues, flyers, magazines and/or web sites).
**Some appliances have been tested with a low ceiling. Before setting up your unit, refer to the installation manual.
1. Unless stated otherwise, measures were taken directly at the main power source and include all electrical components present in the appliance.
2. Optimum overall efficiency at a specific burn rate (LHV).
3. This appliance is officially tested and certified by an independent agency.
4. Based on the maximum burn-rate and a dry energy value of pellet at 8,600 BTU/lb.
5. As measured per CSA B415.1-10 stack loss method.
6. Efficiency based on radiated and delivered heat when allowing cycling from high to low burn to simulate thermostat demand.
7. Lower Heating Value of the fuel.
8. Higher Heating Value of the fuel.
9. The optimum heat transfer efficiency is for the low burn rate (using HHV) and represents the appliance’s ability to convert the energy contained in the solid fuels into energy transferred to the room in the form of heat and does not take into account the chemical losses during combustion.
10. Recommended heating area and maximum burn time may vary subject to location in home, chimney draft, heat loss factors, climate, fuel type, feed rate, fuel level, and other variables. The recommended heated area for a given appliance is defined by the manufacturer as its capacity to maintain a minimum acceptable temperature considering that the space configuration and the presence of heat distribution systems have a significant impact in making heat circulation optimum.
11. Carbon monoxyde.
12. Grades of pellet fuel are determined by organizations such as Pellet Fuels Institute (PFI), ENplus and CANplus.
