Invicta Symphonia 40" Cast Iron Wood Burning Stove 6115-44
Product Description
Let Symphonia captivate your senses. The hypnotic dance of the flames is reflected in the design on the doors of this wood-burning stove. Cozy evenings await, lulled by the sound of the crackling fire. An authentic shape that guarantees excellent performance.
Indulge your senses with Symphonia. The hypnotic dance of the flames will extend on the decorative doors of the wood stove. An authentic design which also demonstrates high performances.
Decorative doors bring the Symphonia model 41 inch wood burning Invicta stove to another level. Made of durable cast iron this stove will last, heating your family for years to come.
Made by the French stove manufacturer Invicta in France, the Symphonia delivers 90,000 BTUs of heat and comes with an advanced secondary-combustion system that increases efficiency, resulting in longer burn times.
Features
8 hour extended burning
The unit can operate in slow combustion mode for 8 hours without adding more fuel or other external intervention. There will be a bed of embers after this period. This is enough to reload the unit with fuel to relight it.
Adjustable secondary air
Secondary air protects the glass against smoke and soot deposits. It ensures combustion of volatile materials. The adjustable secondary air flow can adapt the unit’s operation to high draft conditions.
Clean glass
The clean glass system slows deposit buildup on the glass. An air supply above the glass creates a protective curtain. The preheated air is propelled along the glass. It triggers combustion of gas and volatile materials, thereby protecting the glass against smoke and soot deposits.
Origine France Garantie (Made in France Guarantee)
The Origine France Garantie is the only certification that certifies a product was manufactured in France. This labeling is validated by an independent organization, after an audit. (Bureau Veritas No.7208672). OFG products are manufactured in France at Invicta Group manufacturing sites.
Post-combustion system
Injection of pre-heated air into the combustion chamber The supplementary air intake in the back enables hydrocarbons to be destroyed at a high temperature. Complete combustion reduces pollution.
Technical Elevations
Optional Accessories
Cold rolled steel panel. High temperature anthracite epoxy paint coating. Sometimes you just can't make it work with the clearances required of your wood stove. That's where this Invicta rear heat shield comes in. This shield provides and extra layer to safety during the use of your appliance.
Flue Adaptor
Please Note: Do not connect the stove to any hot air distribution system
Specification
| SPECIFICATION | |
|---|---|
| OPTIMAL POWER | 12 kW |
| POWER MODULATION | 8 to 18 kW |
| HEAT VOLUME | 160 - 360 m³ |
| HEATING SURFACE | 65 to 145 m² |
| GREEN FLAME | 7 stars |
| EFFICIENCY | 77% |
| CO RATE | 0.1% |
| CONCENTRATION OF POWDERS | 30 mg/Nm³ |
| PERFORMANCE INDEX | 0.7 |
| COMBUSTILE | Logs 25, Logs 33, Logs 50 cm |
| MAXIMUM LENGTH OF THE LOGS (HORIZONTALLY) | 71 cm |
| LOAD | Front |
| SMOKE EXHAUST | Top |
| DIAMETER OF NOZZLE | 180 mm |
| DIMENSIONS | H 913 x W 1034 x D 491 mm |
| WEIGHT | 199 kg |
| DESIGN | Contemporain |
| MATTER | Cast Iron |
| COMPLETION | Anthracite |
| CERTIFICATION | EN 13240 |
| GUARANTEE | 5 years |
Resources
Invicta Symphonia Stove Catalog
Invicta Symphonia Stove Installation and Owners Manual
Invicta Symphonia Stove Technical Specification
